Silicone Rotor Industrial Dehumidifier For Factory

Silicone Rotor Industrial Dehumidifier for Factory

silica gel rotor Industrial Dehumidifier for FactoryApplicable to the co-piece glass, electronics assembly, biochemistry, battery factory, rubber tires, etc. Temperature: 15 ~ 25 °C. Relative humidity: 5 ~ 30% RH, dew point -23 °C d p.Air volume: 300 ~ 150000m3 / h.Industrial dehumidifier large capacitySpecificationTypeD

silica gel rotor Industrial Dehumidifier for Factory

Applicable to the co-piece glass, electronics assembly, biochemistry, battery factory, rubber tires, etc. Temperature: 15 ~ 25 °C. Relative humidity: 5 ~ 30% RH, dew point -23 °C d p.
Air volume: 300 ~ 150000m3 / h.

Industrial dehumidifier large capacity

Specification

Type	Dehumidifying Capacity	Air volume	React. Way*	React. Way(electric)	Cold load	Dehumidifying Area	Chiller Power
Type	Kg/h	m3/h	KW	KW	KW	m3	KW
ZHS-250	6.2~15	300~1200	-	5.6~7	18~35	30~50	5.9~11.5
ZHS-350	12.5~19.8	600~2400	-	11~22	18~43	50~80	5.9~14.2
ZHS-450	17.2~31.4	1200~5000	4.5~7	15~28	43~86	80~150	14.2~28.4
ZHS-550	32~62	2400~8000	5~13	22.5~36	38~120	150~300	12.5~39.6
ZHS-770	50~130	5000~9500	5.5	43~80	45~136	300~450	14.9~44.9
ZHS-950	70~220	7000~15000	7.5	68~110	72~174	450~750	23.8~52.2
ZHS-1200	150~420	10000~28000	13~18	116~220	132~356	750~1400	43.6~106.8
ZHS-1500	250~780	15000~25000	22~27	-	183~566	1400~2150	54.9~169.8
ZHS-1900	320~960	20000~75000	28~36	-	290~901	2150~3500	87~270.3
ZHS-2400	380~1300	30000~115000	42~53	-	495~1397	3500~5750	148.5~419.1
ZHS-3000	720~2100	45000~150000	75~88	-	620~1820	5720~7500	186~546

Selection method:
1.Temperature and humidity requirements.
2.Length, width and height.
3.Air volume, ventilation times, supply air temperature.
4.Dry Room Clean class.
5.The number of staff.
6.Whether cold water and steam available.
